Newland BS8060 Piranha Bluetooth Pocket Scanner

Newland BS8060 Piranha Bluetooth Pocket Scanner

The Newland Piranha Bluetooth Barcode Scanner can be defined by its snappy reading performance and portability, providing the convenience of always having a scanner at your fingertips. With dimensions of 88 x 46 x 24.5mm it is small enough to fit into a pocket and light enough to carry around all day. Despite its small size, the Piranha maintains an excellent performance, scanning virtually all 1D/2D barcodes seamlessly.

Newland BS8060 Piranha Bluetooth Smartphone PDA Scanner

Description

FEATURED

  • Superior reading performance.
    The Newland BS8060 Piranha Bluetooth Barcode Scanner is offered in 2 versions, containing a 1D or a 1D+2D engines. These engines are capable of reading virtually any barcode from paper or screen. The 2D device has been equipped with a laser aimer with a red cross to make barcode reading easier and faster.
  • Convenient communication.
    Use the interface that suits your application best. The Newland BS8060 Piranha gives you the flexibility to choose your preferred communication method with options like HID keyboard and Virtual COM.
  • Easy Bluetooth pairing.
    Via Bluetooth 4.0 Class 1 wireless technology, the Newland BS8060 can be paired with any Android, iOS or Windows device, five times faster than regular Bluetooth.
  • Can be used anywhere, anytime.
    The Newland BS8060 Piranha is small enough to fit into your pocket and light enough to carry around all day, providing you with the convenience of always having a scanner at your fingertips.
  • Hassle-free battery capacity
    The high capacity Li-ion battery in the scanner provides up to 11 hours of continuous use per charge, allowing you to work hassle-free all day.

Summary

SUITABLE APPLICATIONS

  • Mobile payments
  • E-coupons/e-vouchers
  • Retail store management
  • Price verification
  • Inventory Management
  • Distributor Management and more

Specifications

Performance

  • Model:
    Newland BS8060 Piranha
  • Image Sensor:
    2500 Linear Imager
    752×480 CMOS
  • Symbologies:
    1D: Code 128, EAN-13, EAN-8, Code 39,
    UPC-A, UPC-E, Codabar, ISSN, Interleaved 2 of
    5, ISBN, Code 93, UCC/EAN-128, GS1 Databar,
    etc.
  • 2D: PDF417, QR Code, Data Matrix, etc.
    1D: Code 128, EAN-13, EAN-8, Code 39, UPC-A,
    UPC-E, Codabar, ISSN, Interleaved 2 of 5, ISBN,
    Code 93, UCC/EAN-128, GS1 Databar, etc.
  • Resolution:
    ≥5mil
  • Typical Depth of Field:
    Code 39 105mm-175mm (5mil)
    Code 128 6 0mm-340mm (10mil)
    EAN-13 55mm-410mm (13mil)
    EAN-13 55mm-360mm (13mil)
    Code 39 45mm-160mm (5mil)
    Data Matrix 40mm-115mm (10mil)
    QR Code 45mm-140mm (15mil)
    PDF 417 50mm-105mm (6.67mil)
  • Scan Angle:
  • Pitch: ±55°; Roll: ±25°; Skew: ±75°
  • Pitch: ±50°; Roll: 360°; Skew: ±60°
  • Min. Symbol Contrast:
    30%
  • Interface:
    Micro USB, Bluetooth HID/SPP/BLE profiles
  • Bluetooth Transmission:
    100m (open space)
  • Wireless Standards:
    2.4 – 2.5GHz ISM band, compatible with Bluetooth 4.0/3.0/2.1+EDR
  • Memory Capacity:
    1MB (capable of storing the data of over 20,000 EAN-13 barcodes)

Mechanical / Electrical

  • Dimensions:
    88.0(L)×46.0(W)×24.5(H)mm
  • Weight:
    62g
  • Notification:
    Sound, LED and vibration
  • Battery:
    3.7V 900mA rechargeable Li-ion battery
  • Expected Battery Life:
    11 hours of continuous operation (Synchronous mode, scan and send data once per 6s)
    6 hours of continuous operation (Synchronous mode, scan and send data once per 6s)
  • Expected Charge Time:
    3.5 hours
  • Power Adapter (Optional):
    Output: DC 5V, 500mA
    Input: AC100 ~ 240V, 50~60Hz
  • Current:
    Operating Current: 75mA (Bluetooth is on)
    Standby Current: 5mA
  • Operating Current: 260mA (Bluetooth is on)
    Standby Current: 10mA

Environmental

  • Operating Temperature:
    -20℃ to 50℃ (-4°F to 122°F)
  • Storage Temperature:
    -40℃ to 70℃ (-40°F to 158°F)
  • Humidity:
    5%~95% (non-condensing)
  • ESD:
    ±8 KV (Contact discharge);
    ±15 KV (Air discharge)
  • Drop:
    1.2m
  • Sealing:
    IP42
  • Certification:
    FCC Part15 Class B, CE EMC Class B

Operating Conditions

  • Operating Temperature:
    -20℃~50℃
  • Storage Temperature:
    -30℃~70℃
  • Industrial Protection:
    IP68, 1.5m drop (with protection shell)
  • Laser Safety:
    IEC2 / FDA II, IEC60825 / EN60825-1
  • Certificates:
    CTA, CCC, CE

Product – Kit

Unit include Power Supply and Cables
