Urovo A100 Industrial RFID Barcode Reader

Urovo A100 Industrial RFID Barcode Reader

As a Handheld UHF RFID reader, A100 could read electronic tags rapidly in batches and from a long distance, besides A100 also could read barcode label, which could meet the requirement for data collection in different complicated scenarios. The data will be transferred to a smartphone and portable device by Bluetooth after tag and label identified.

UROVO A100 BROCHURE

UROVO A100 REFERENCE GUIDE

Description

FEATURED

  • FAST READING
    Max 500 tags/Second
  • LONG READING DISTANCE
    The maximum reading distance could reach 20 meters
  • ACCURATE DATA CAPTURING
    100% accuracy
  • BIG DATA STORAGE
    Store 50000 Tags ID
  • LIGHT-WEIGHT AND EASY TO BE CARRIED AND HANDLED

Summary

A100 Industrial RFID Reader

As a Handheld UHF RFID reader, A100 could read electronic tags rapidly in batches and from a long distance, besides A100 also could read barcode label, which could meet the requirement for data collection in dif ferent complicated scenarios. The data will be transfer red to smar tphone and por table device by Bluetooth after the tag and label identified.

Specifications

BASIC CHARACTERISTICS

  • CPU:
    STM32F103ZET6
  • Display:
    1.3” White OLED LCD (128*64)
  • Bluetooth:
    BT 4.1 + BR/EDR + BLE, Class 2
  • Dimension:
    216mm X 105mm X 34mm
  • Weight:
    250g(Battery Included, Weight will be a little different depend on Different configuration )
  • Battery:
    Rechargeable 4.2V, 3100mA/h Lithiumion battery
  • Audio:
    Buzzer
  • Operating Temperature:
    -10 ~ 50oC
  • Storage Temperature:
    -20 ~ 70oC
  • Humidity:
    5% RH- 95% RH( non condensing)
  • Drop Durability:
    1.5M

BARCODE SCANNER

  • 1D:
    UPC/EAN, Code128, GS1-128, Code 39,
    Trioptic 39, Code 32, Code 93, Code11,
    China Post, Matrix 2 of 5, Interleaved 2 of 5,
    Industrial 2 of 5, Codabar, MSI, GS1 DataBar
  • 2D:
    PDF417, MicroPDF417, Composite Code, Data
    Matrix, Maxicode, QR Code, MicroQR, Aztec,
    Han Xin
  • Scanning Rate:
    100±10times/second

RFID

  • Tag ID Storage:
    50,000 EA, 192Bit
  • Power:
    MAX, +30dBM(1watt), 1dBm adjustable
  • Frequency:
    840-960MHz(Customizable)
  • EPC:
    C1 GEN2/ISO18000-6C
  • Maximum Reading Rates:
    >500pcs/second
  • Reading Distance:
    Maximum 20 meters(Effective reading distance depends on Tags and Working Environment)
  • Scanning Angle:
    Maximum 110°

Product

Unit include Power Supply and Cables

Build-On Scan Engine

Optional extras – Scan engine option needs to be included at manufacture stage
