Zebra ZT410 Industrial Barcode Label Printers

Zebra ZT410 Industrial Barcode Label Printers

Fast and reliable, the ZT420 has a print width of 6 inches and can print up to 12 ips.

Description

FEATURED

  • Thermal transfer and direct thermal printing
  • Metal frame and bi-fold metal media cover with enlarged clear viewing window
  • Side-loading supplies path for simplified media and ribbon loading
  • Element Energy Equalizer™ (E3™) for superior print quality
  • Communications: USB 2.0, high-speed, RS-232 Serial, 10/100 Ethernet, Bluetooth 2.1, USB Host
  • Back-lit, multiline graphic LCD display with intuitive menu and easy-to-use keypad for quick operation
  • Bi-coloured status LEDs for quick printer status
  • ENERGY STAR® qualified

Summary

Built to last

The Zebra ZT420 builds on the field-proven reliability of the Z Series™ with advancements in print speed, print quality and connectivity options. Designed for ease of use, the ZT420 Series printers offer an intuitive icon-based LCD graphical user interface and easy supplies loading. And, they include standard USB, Serial, Ethernet and Bluetooth® capabilities. Expanded RFID capacities deliver greater tracking abilities, deeper visibility and enterprise insights.

Easy to Operate

Zebra ZT420 is dynamic QR codes provide on-demand, web-based support to resolve printer errors quickly. ZT410 has a print touch-enabled Link-OS printers offer web page launching features using Near Field Communication (NFC), making it easy to access Zebra’s extensive knowledge base of how-to videos and product support. Also lighted media and ribbon paths make it easy to see inside the printer, even in poorly lit environments.

Effortless to Integrate

USB host port enables simple printer configuration by easily transferring data from a USB flash drive via mirroring and expanded mapped-drive memory capabilities.

Virtual Devices apps enable Link-OS printers to support well-known legacy and competitor printer languages—in addition to ZPL® and EPL™—for a future-proofed investment.

Simple to Manage

Zebra’s ZT420 Link-OS environment delivers enhanced capabilities to monitor, manage and maintain your printer from any location. Cloud Connect allows Link-OS printers to securely and directly interact with the Cloud for printing and device management. With Zebra ZT420 Profile Manager enables you to edit and manage one printer, batches of printers or all Link-OS printers across your network anywhere in the world..

Application Flexibility

Expand your printing readiness through an exceptional range of media capabilities and media. delivery options.
Customize your printer to match your current and future business needs with end-user-installable media handling options.
Standard Serial, USB, Ethernet and Bluetooth features—as well as two open media slots—allow you to utilize non-standard connectivity options.
Expanded RFID capabilities are easy to install and simple to use.
Ensure quality output for small-label applications with high-resolution printing capabilities.

SUITABLE APPLICATIONS

  • Shelf labelling
  • Price marking
  • Banking
  • Quotation printout
  • File/Folder labelling
  • Stationeries labelling
  • Assets tracking
  • Logistic labelling
  • Packing
  • Inventory labelling
  • Utilities
  • Shipping & Receiving
  • Postal & mailing
  • Luggage labelling
  • Work in process
  • Parts marking
  • Product labelling
  • Compliance labelling
  • Pallet labeling
  • Electronics parts labelling
  • Materials Management
  • Patient tracking
  • Laboratory specimen labelling
  • Pharmacy labelling
  • Healthcare Materials Management
  • Hospitals
  • Invoicing
  • Document Printing
  • Check-in
  • Education and Libraries

Specifications

DECODING CAPABILITY

  • 1D / Linear Codes:
    Linear Codabar; Code 11, Code 39, Code 93, Code 128 with subsets A/B/C and UCC Case Codes, ISBT-128, UPC-A, UPC-E, EAN-8, EAN-13, UPC and EAN 2- or 5-digit extensions, Plessey, Postnet, Standard 2-of-5, Industrial 2-of-5, Interleaved 2-of-5, Logmars, MSI, Codabar, Planet Code
  • 2D Codes:
    2-Dimensional Barcodes: Codablock, PDF417, Code 49, DataMatrix, MaxiCode, QR Code, TLC 39, MicroPDF, RSS-14 (and composite), Aztec

PRINTER SPECIFICATIONS

  • Resolution:
    203 dpi (8 dots/mm)
    300 dpi/12 dots per mm (optional)
  • Memory Standard:
    256 MB SDRAM
    512 MB Flash
  • Print Width:
    6.6″ (168 mm)
  • Print Length:
    Length with 203 dpi: 157″ (3988 mm)
    Length with 300 dpi: 73″ (1854mm)
    Length with 600 dpi: 39″ (991mm)
  • Print Speed:
    12″ (305 mm)/sec)
  • Media Sensors:
    Dual media sensors: transmissive and reflective

MEDIA CHARACTERISTICS

  • Maximum Label & Liner Width:
    7.0″ (178 mm) – tear & cutter
    6.75″ (171 mm) – peel & rewind
  • Maximum Label & Liner Length:
    39”(991 mm)
  • Maximum Roll Diameter:
    8″ (203 mm)
  • Core Diameter:
    3.0”(76 mm)
  • Media Thickness:
    0.0023″(0.058 mm) to 0.010″(0.25 mm)
  • Media Types:
    Continuous, die-cut, notch, black mark

RIBBON CHARACTERISTICS

  • Outside Diameter:
    3.2″ (81.3 mm)
  • I.D. core:
    3”(76 mm)xx
  • Standard Length:
    1476’(450 m)
  • Ratio:
    2:1 media roll to ribbon ratio
  • Ribbon Width:
    2″ (51 mm) to 6.85″ (174 mm)
  • Ribbon Setup:
    Ribbon wound ink-side out; ribbon wound ink-side in can be used with the optional ribbon spindle

OPERATING CHARACTERISTICS

  • Operating Temperature TT Model:
    40° F (5° C) to 105° F (40° C)
  • Operating Humidity:
    20-85% non-condensing R.H
  • Storage Humidity:
    5-85% non-condensing
  • Electrical:
    Auto-detectable (PFC Compliant) 100-240VAC, 50-60Hz, rated at 100 Watts

PHYSICAL CHARACTERISTICS

  • Width:
    13.25″ (336.55 mm)
  • Height:
    12.75″ (324 mm)
  • Depth:
    19.50″ (495 mm)
  • Weight:
    40 lbs (18.14 kg)
  • Orientation:
    Center
  • Core Programming Languages:
    ZPL, ZPL II, EPL, XML

Product – Kit (ZT410 Series)

Printers include Power Supply and Cables

Accessories/ Consumables

Optional extras

Maintenance Repair Agreements (Per Unit)

Repair Maintenance Agreements or Ease of care repairs with a turnaround of 5-7 days from date of order
